Enchant

Shelf Edge Display | Digital Signage

Specification

Model (Shelf Edge Display)		Enchant 23.1" (EG-2310)	Enchant 35" (EG-3500)	Enchant 47.1" (EG-4710)	Enchant 23.1" with Touch (EG-2310T)	Enchant 36" (EG-3600)
Dimension W x H x D (mm)		597 x 60 x 16	892 x 60 x 16	1212 x 68 x 26	594 x 63 x 20	900 x 270 x 34
Screen Size and Type		23.1"	35"	47.1"	23.1" with Touch	36"
Display Size	Pixels	1920 x 158	2880 x 158	3840 x 158	1920 x 158	1920 x 532
Display Size	mm	588 x 50	880 x 50	1196 x 50	588 x 50	881 x 242
Operating Temperature		0°C to 40°C			0°C to 40°C
Display Technology		TFT LCD			TFT LCD
Compliance		CE, TELEC, RoHS	CE, TELEC, RoHS	CE, RoHS	CE, RoHS
Operating Humidity		20% to 80% RH Non-Condensation			20% to 80% RH Non-Condensation
Operating System		Android			Android
Communication Mode		WiFi 2.4G			WiFi 2.4G
Power Source		DC12V			DC12V
Hardware Interface		Mircro USB x1, TF Card x1, DC_IN x1	USB2.0 x1, Mircro USB x1, Micro SD Card x1	USB2.0 x1, USB OTG x1, TF Card x1, DC_IN x1, RESET x1	Mircro USB 2.0: Host x1, OTG x1	Mircro USB 2.0 x1
Content Format		JPEG, PNG, BMP, GIF, MP4, MKV			JPEG, PNG, BMP, GIF, MPEG-1/2, MVC, GOOGLE VP8, H.263, MOTION JPEG	JPEG, PNG, BMP, GIF, MP4, MKV
Net Weight		0.66kg	1.09kg	2.72kg	0.82kg	7kg
