HC-700
Many automatic labelling functions for the food industry with proven results
Dimensions
| Dimension of product for labeling(Recommended) | Width: 50 ～ 240mm | |
|---|---|---|
| Length: 70 ～ 350mm | ||
| Height: 15 ～ 190mm | ||
| Label dimensions | Top application(Standard cylinder) | Width: 40 ～ 80mm |
| Length: 28 ～ 100mm | ||
| Top application(High-precision cylinder) | Width: 20 ～ 80mm | |
| Length: 20 ～ 100mm | ||
| Bottom application | Width: 40 ～ 80mm | |
| Length: 28 ～ 80mm | ||
| Power consumption(standby/operation) | 82Ｗ/295W | |
| Main unit dimension | W681ｘL750ｘH1545mm | |
| Conveyor height | 800±50mm | |
| Power supply | Main unit:single phase 220-240v | |
| Air source | Top application:max1.6/Label Bottom application:max 2.36ℓ/Label | |
